Chalcopyrite, arsenopyrite, pyrite, sphalerite and native gold. Clogau Mine, Wales, Britain




Click here



250µm


Arsenopyrite (white, centre) is highly fractured and these fractures are infilled by sphalerite (light grey, centre left), native gold (yellow-white, high reflectance, poorly polished, centre) and chalcopyrite (yellow). Chalcopyrite also encloses much of the arsenopyrite. A euhedral cube of pyrite (light yellow-white, right centre) has lower reflectance than arsenopyrite. Dark grey area is quartz (bottom). The native gold is 950 fine, and to the eye has a higher reflectance than the photomicrograph would suggest.


Polished block, plane polarized light, x 80, air
