Uraninite and chalcopyrite. Port Radium, Northwest Territories, Canada




Click here



500µm


Coarse botryoidal uraninite (light grey, bottom) is accompanied by smaller botryoidal uraninite, 'blasenblende' (top). Chalcopyrite (yellow, centre bottom) lies along fractures and shrinkage cracks of the uraninite. The carbonate gangue shows bireflectance (top left).


Polished block, plane polarized light, x 40, air
