Pyrite, niccolite, vaesite, rammelsbergite and marcasite. Settlingstones Mine, North Pennines, Britain




Click here



125µm


Niccolite (pink, bottom) shows faint reflection pleochroism and bireflectance. It is altered along grain edges and along fractures to rammelsbergite (blue-white, centre bottom) accompanied by vaesite (violet-brown with cleavage, centre, top right). A central vein of coarse-grained pyrite (yellow-white) is intergrown with marcasite (green-blue, centre). Black areas are gangue minerals.


Polished block, plane polarized light, x 160, oil
