Haematite and magnetite. Skye, Scotland




Click here



125µm


Haematite (white, right) is coarse-grained and shows very faint bireflectance along (101 1) twin planes, which are oriented north-south but difficult to see in plane polarized light. Magnetite (pink-brown, bottom left) is well polished. Dark grey areas are silicates, black areas are polishing pits.


Polished block, plane polarized light, x 80, air
