Wolframite and cassiterite. Glen Gairn, Scotland




Click here



125µm


Euhedral cassiterite (grey, bottom centre) is twinned, shown by the differences in bireflectance (light and dark grey). Tabular wolframite (light grey-brown and grey-blue) is zoned, the inner zone is blue and the outer zone is grey-brown. Quartz (top left) and feldspar (bottom centre) show internal reflections, some of which are due to limonitic staining (orange, bottom right).


Polished thin section, plane polarized light, x 160, oil
